Cylinder

A round body with caps, which can also become a truncated cone.

Cylinder
Cylinder

The Cylinder is a round body closed by two caps. With different radii at the top and bottom, it becomes a vase or a tapering trunk.

Properties

Geometry
Top Radius
1
Bottom Radius
1
Height
2
Radial Seg.
10
Corner Radius
0
Corner Seg.
4
Texture
Mapping
  • Top Radius and Bottom Radius: The top and bottom radii, in meters.
  • Height: The height, in meters.
  • Radial Seg.: How many sides. Few sides make a prism.
  • Corner Radius: Rounds the edges of the caps.
  • Corner Seg.: How smooth the rounding is. With 1, the corner becomes a straight bevel.

For a hollow pipe, use the tube. For a tip, use the cone.
